8-SPECIFICATIONS
LEEN11T0120FA14
1121FXRSpecications-4.8m³(6.27yd³)Bucket
Bolt-onEdgeBucket
w/TeethBucket
ISOBucketSpecications
Struck4.17m³(5.45yd³)4.01m³(5.25yd³)
Heaped
4.78m³(6.25yd³)4.63m³(6.06yd³)
Bucketwidth(maximumouter)3195mm(125.8in)3195mm(125.8in)
DimensionalOutlineSpecications
A(topofcabheight)3573mm(140.6in)3573mm(140.6in)
B(wheelbase)3550mm(139.8in)3550mm(139.8in)
C(groundclearance)509.4mm(20.1in)509.4mm(20.1in)
D(rearangleofdeparture)34°34°
Overallwidthwithbucketguard2990mm(117.7in)2990mm(117.7in)
Centerlinetreadwidth2250mm(88.6in)2250mm(88.6in)
Turningradius(outsideoftires)6372mm(250.9in)6372mm(250.9in)
Turninganglefromcenter40°40°
Totalturningangle
80°80°
E(fullyraisedwithspillguard)6537mm(257.4in)6537mm(257.4in)
F(hingepin-fullyraised)4860mm(191.3in)4860mm(191.3in)
G(overall-bucketlevelonground)9526mm(375in)9707mm(382.2in)
H(dump-fullyraised,45°dump)3619mm(142.5in)3503mm(137.9in)
J(reach-fullyraised,45°dump)1316mm(51.8in)1454mm(57.3in)
K(reach-2.13m(7.0ft),45°dump)2415mm(95.1in)2505mm(98.6in)
L(digdepth)119mm(4.7in)119mm(4.7in)
ISOLoadSpecications
Operatingload7753kg(17092lb)7808kg(17214lb)
Tippingload
Machinestraight
40°turn
18319kg(40386lb)
15506kg(34185lb)
18449kg(40673lb)
15616kg(34428lb)
