8-SPECIFICATIONS
LEEN11T0120FA15
1121FXRSpecications-5.0m³(6.53yd³)BucketFlatBottomwithBlade
Bolt-onEdgeBucket
ISOBucketSpecications
Struck4.40m³(5.75yd³)
Heaped
5.0m³(6.54yd³)
Bucketwidth(maximumouter)3175mm(125in)
DimensionalOutlineSpecications
A(topofcabheight)3573mm(140.6in)
B(wheelbase)3550mm(139.8in)
C(groundclearance)509.4mm(20.1in)
D(rearangleofdeparture)34°
Overallwidthwithbucketguard2990mm(117.7in)
Centerlinetreadwidth2250mm(88.6in)
Turningradius(outsideoftires)6372mm(250.9in)
Turninganglefromcenter40°
Totalturningangle
80°
E(fullyraisedwithspillguard)6616mm(260.5in)
F(hingepin-fullyraised)4859mm(191.3in)
G(overall-bucketlevelonground)9696mm(381.7in)
H(dump-fullyraised,45°dump)3509mm(138.2in)
J(reach-fullyraised,45°dump)1446mm(56.9in)
K(reach-2.13m(7.0ft),45°dump)2500mm(98.4in)
L(digdepth)119mm(4.7in)
ISOLoadSpecications
Operatingload7643kg(16850lb)
Tippingload
Machinestraight
40°turn
18100kg(39903lb)
15286kg(33700lb)
8-43
