3-CONTROLSANDINSTRUMENTS
5.Heightadjustmenthandle:
A.AutomaticAdjustment-Withtheoperatorsitting
intheseat,liftthehandleUPuntilthedesired
heightisreached.Releasetheweightadjustment
tab.Performa"hop"movement,brieyremoving
weightfromtheseat,thenregainsittingposition
andreapplyweight.Thiswillresettheheightlatch.
B.Tolowertheseat,pushdownandholdtheweight
adjustmenttabuntilthedesiredheightisreached.
Releasetheweightadjustmenttabandperform
the“hop”movement,brieyremovingweightfrom
theseat,thenregainsittingpositionandreapply
weight.Thiswillresettheheightlatch.
NOTE:Ifthe"hop"movementisnotperformed,the
seatwillreturntoitsformerlatchpoint.
C.ManualAdjustment-Theseatcanberaisedor
loweredbyincreasingordecreasingtheairpres-
sureintheseat.LiftthehandleUPtoincreasethe
airpressure.PushthehandleDOWNtodecrease
theairpressureandlowertheseat.
RCPH10WHL092BAL9
6.Seatdepthhandle-Lifthandleupandmovethecush-
iontothedesiredposition.Releasethehandletolock
thecushioninplace.
7.Seatcushionangleadjustmenthandle-Liftuponthe
handle.Movetheseattothedesiredangle.Release
thehandletolockthecushionangle.
Weightindicator,standardseat-Theweightindicator
islocatedatthebottomoftheseat.Useittoadjustto
theoperator'sweightforamorecomfortableride.
RCPH10WHL092BAL10
8.Ridecushionadjustmentlever-Theseatsuspension
canbeadjustedtovariousoperatingconditionsinor-
dertogainthemostcomfortableridefortheoperator.
Thecushionadjustmentleverhasfourpositionsfrom
softtohardinordertoallowformaximumcomfortover
varyingorroughterrain.
Therstadjustmentiswiththesmallendofthead-
justmentleverpointingtowardthefrontoftheseat,as
shown.Theotherthreeadjustmentscanbeobtained
byrotatingthesmallendoftheadjustmentleverout
awayfromtheseat.Eachoftheadjustmentshasa
slightdetent.
WeightAdjustment:Liftorpresshandleuntilthegreen
markingattheweight/heightindicatorisvisible.
HeightAdjustment:Liftorpresshandleuntilthere-
quiredpositionisadjusted(Thegreenmarkingisvisi-
bleontheindicatoratthebottomfrontoftheseat).
RCPH10WHL424AAH11
3-6
