M-Series Operator’s Manual 4/9/15 2-8
Hot Key Action
ALT J Enables keyboard jogging*
ALT K Displays current ATC tool bin location
ALT M MDI
Ctrl T Tool check*
ALT P Live PID display
CTRL P Clear max and min error display
Ctrl C Spindle CW*
Ctrl W Spindle CCW*
Ctrl S Start Spindle*
Ctrl Q Stop Spindle
ALT S Cycle start
ALT T Displays current motor temperature estimates
ALT V Displays current software version #
ALT W MPG on/off*
ALT + / ALT - Selects next/previous WCS, cycles through WCS 1-18**
ALT 1 - ALT 0 Selects WCS 1 – WCS 10**
ALT Tab Cycle through currently running applications
CTRL F1 - CTRL F12
Executes Aux function 1 – 12*
CTRL V Enables/disables Stall detection in PID Configuration***
CTRL I Creates plcstate.txt when PLC diagnostics is displayed***
CTRL E Starts the PLC Debugger***
Notes: * This is a keyboard jog panel function.
** Not available during jobs or on jog panel.
