M-Series Operator’s Manual 4/9/15
15-1
Chapter 15
CNC Software Messages
CNC software startup errors and messages
Error Message Cause & Effect Action
102 Error initializing
CPU...cannot
continue.
Error while sending .hex file. Cannot
communicate with MPU11 or it is not plugged
in.
Inspect MPU11 connection
, or fix
missing or corrupted hex file.
Contact Dealer
103 Error sending
setup
Unable to send setup command to MPU11.
Cannot communicate with MPU11 or it is not
plugged in.
Inspect MPU11 connection, or fix
missing or corrupted hex file.
Contact Dealer
104 Error sending PID
setup
Unable to send PID setup command to
MPU11. Cannot communicate with MPU11 or
it is not plugged in.
Inspect MPU11 connection, or fix
missing or corrupted hex file.
Contact Dealer
105 mpu.plc file read
error..cannot
continue
Missing or error in mpu.plc. Contact dealer
Install or recompile PLC
program.
106 The PC clock
appears to be
wrong
The time on the PC internal clock is earlier
than the time recorded in a previously stored
file
199 CNC started CNC control software has started.
Messages issued upon exit from CNC software
Error Message Cause & Effect Action
201 Exiting CNC due to a
known error
MPU11 not responding, or mpu11.hex,
mpu.plc is missing or damaged.
Contact dealer
Check for possible software
corruption
202
Exiting CNC due to a math
error
A floating-point math error occurred.
Possible corruption of cnc.tem,
cncm.job, or cncm.wcs.
Contact dealer
Delete corrupted files and reboot
software.
204 Exiting CNC...Normal Exit CNC control software is shuting down
normally.
222 Autotune run added to log whenever autotune is run
Messages and Prompts in the Operator Status Window Status messages
Error Message Cause & Effect Action
301 Stopped No operations in progress
302 Moving... Motors are moving while a CNC program is
running
303 Paused... Motion is paused while a CNC program is running
(FEED HOLD)
304 MDI... CNC software running in MDI mode
305 Processing... CNC software running in a mode other than MDI
306 Job finished Normal end of CNC program
