M1000-M1015 ā Graphing Color for Feedrate movement
When a CNC program is graphed (F8 from the Main Screen), feedrate movements are normally plotted using the
color yellow. This color setting can be changed to another color as stated in the chart below.
M Code Feedrate
Graphing Color
M Code Feedrate
Graphing Color
M1000 black M1008 maroon
M1001 Navy blue M1009 purple
M1002 green M1010 olive
M1003 teal M1011 gray
M1004 orange M1012 red
M1005 blue M1013 fuschia
M1006 lime M1014 yellow
M1007 aqua M1015 white
Changing this feedrate graphing color can be used as a method highlighting or hiding parts of a graphed CNC
program, but will not affect the normal run of the program (when the CYCLE START button is pressed on the Main
Screen). The limitations to using these M codes are as follows: These M codes cannot be placed on the same line
as another M code, and also the rapid (G0) movement color cannot be changed.
