F5 – CAM
Choose F5-CAM to program parts. The default part programming system is Intercon. Intercon is a
conversational programming system that allows you to quickly and easily create a part program. Intercon
features many easy to use canned cycles for most common machining operations such as: rectangular,
circular and irregular pockets, pockets with islands, bolt hole circles, frames, thread milling operations and
much more. When you are finished programming your part in Intercon, exit to return to the M-Series
Control Main Screen and the posted Intercon program will be automatically loaded and ready to run. For
more information on Intercon, see chapter 10.
F1 – ICN Intercon conversational program system
F2 – Engrave DXF engrave option (optional item part of DXF Import) allows you to import an entire DXF
drawing and engrave it onto a part.
F3 – Milwrite Millwrite Engraving software (optional item) allows you to create engraving files to engrave
letters, numbers, and symbols on your parts.
F4 – Manual Allows you to access the operator manual on the control
ICN
ICNICN
ICN
-
--
-
Intercon Mill
Intercon Mill Intercon Mill
Intercon Mill
Engrave
EngraveEngrave
Engrave -
--
- DXF Engraving
DXF EngravingDXF Engraving
DXF Engraving
Milwrt
MilwrtMilwrt
Milwrt -
--
- Millwrite Engraving
Millwrite Engraving Millwrite Engraving
Millwrite Engraving
Help
HelpHelp
Help -
--
- Operators Manual
Operators Manual Operators Manual
Operators Manual
CAM Selection
