M-Series Operator’s Manual 4/9/15 15-11
Number
Message Cause & Effect Action
605 Canned cycle not allowed on
line NNNNN
Canned cycle attempted during
compensation. Job cancelled.
Do not use cutter comp.
with canned cycles.
606 G53 not allowed on line
NNNNN
G53 attempted during compensation. Job
cancelled.
Choose a different work
coordinate.
607 Set home not allowed on line
NNNNN
M26 attempted during compensation. Job
cancelled.
Do not use M26 with
cutter comp.
608 Ref. point move not allowed
on line NNNNN
G28, G29, or G30 attempted during
compensation. Job cancelled.
Do not use return points
with cutter comp.
Parameter setting errors
Number
Message Cause & Effect Action
701 G10 error: no R-value on line
NNNNN
G10 used with no R-value. Job
cancelled.
Input an R-value.
702 G10 error: invalid D on line NNNNN Job cancelled (D0 cannot be set; it is
always zero).
Change D to a valid
value.
703 G10 error: invalid H on line NNNNN G10 H0 Rxx specified. Job canceled
(H0 cannot be set; it is always zero).
Change H to a valid
value.
704 G10 error: invalid P on line NNNNN G10 used with unknown P va
lue. Job
cancelled.
Change P to a valid
value.
705 G10 error: No D, H, or P on line
NNNNN
G10 used without D, H, or P to
assign value. Job cancelled.
Add appropriate D, H,
or P value.
Canned cycle errors
Number
Message Cause & Effect Action
801 Error: No R point on line
NNNNN
No R-value specified. Job cancelled. Add an R-point.
802 Error: Q = 0 on line NNNNN Q value of 0 specified (Q used for G73 and
G83 only). Job cancelled.
Insert a Q non-zero
value.
803 Error: No Z point on line
NNNNN
No Z value specified for canned cycle. Job
cancelled.
Add a Z-value.
804 Error: Ggg invalid on line
NNNNN (gg = 76, 86, 87, 88)
Unimplemented canned cycle requested. Job
cancelled.
Change to a valid G-
code.
805 Error: No Q value on line
NNNNN
Q value not specified for G73 or G83. Job
cancelled.
Insert a Q-value.
806 Error: No P value on line
NNNNN
P value (dwell time) not specified for G82
or G89. Job cancelled.
Add a P-value.
807
Error: Cannot execute G__ when
axis B is rotated
On an Articulated Head machine with
TWCS feature enabled, a non-compound
canned cycle (such as G73, G74, G76, G80,
G81, G82, G83, G84, G85, G89) was issu
ed
on a WCS that was set to TWCS=No while
the spindle head was tilted (i.e.
rotary B axis
was not 0). Job cancelled.
Either move B to 0 or
issue the compound
canned cycle version
of the erroneous G-
code such as G173,
G174, G176, G181,
G182, G183, G184,
G185, G189.
