M-Series Operator’s Manual 4/9/15
8-14
Cut Feedrate: The replay feedrate. This is the feedrate that will be output to the file specified by the Digitize File
Name above. This will cause the digitized data to be replayed at this specifed feedrate when the output data is run
as a CNC job.
Cut Direction: The Clockwise or Counter Clockwise direction of the output data. This also defines the direction of
digitze.
Wall Following Digitizing Notes
The output data is uncompensated. Therefore the resultant output data points will be offset by the probe tip’s radius
amount. If you want to run this data as a CNC job and actually do cutting, you must use a cutter that is the same
shape and diameter as the probe tip. An alternative to this is to use a CAD/CAM software package to remove the
probe tip offset and to apply the desired compensation.
