Cisco Catalyst 3750 Software Configuration Guide

iii
Catalyst 3750 Metro Switch Software Configuration Guide
78-15870-01
CONTENTS
Preface xxxiii
Audience xxxiii
Purpose xxxiii
Conventions xxxiv
Related Publications xxxv
Obtaining Documentation xxxv
Cisco.com xxxv
Ordering Documentation xxxvi
Documentation Feedback xxxvi
Obtaining Technical Assistance xxxvi
Cisco TAC Website xxxvi
Opening a TAC Case xxxvii
TAC Case Priority Definitions xxxvii
Obtaining Additional Publications and Information xxxviii
CHAPTER 1 Overview 1-1
Features 1-1
Default Settings After Initial Switch Configuration 1-8
Network Configuration Examples 1-11
Multidwelling or Ethernet-to-the Subscriber Network 1-11
Ethernet Broadband Aggregation Network 1-13
Layer 2 VPN Application 1-14
Layer 3 VPN Application 1-15
Where to Go Next 1-16
CHAPTER 2 Using the Command-Line Interface 2-1
Understanding Command Modes 2-1
Understanding the Help System 2-3
Understanding Abbreviated Commands 2-4
Understanding no and default Forms of Commands 2-4
Understanding CLI Error Messages 2-5

Cisco Catalyst 3750 Specifications

General

Device Type	Switch
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
RAM	128 MB
Jumbo Frame Support	Yes
Switch Type	Managed
Model	Catalyst 3750 Series
Uplink Interfaces	SFP
Form Factor	Rack-mountable
MAC Address Table Size	12, 000 entries
Routing Protocol	RIP, OSPF, EIGRP
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Layer 3 switching, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology
Power over Ethernet (PoE)	PoE
Operating Temperature	-5 - 45 °C
Operating Humidity	10% to 85% non-condensing
