Cisco Catalyst 3750 Software Configuration Guide

CHAPTER
27-1
Catalyst 3750 Metro Switch Software Configuration Guide
78-15870-01
27
Configuring EtherChannels
This chapter describes how to configure EtherChannels on Layer 2 and Layer 3 ports on the
Catalyst 3750 Metro switch. EtherChannel provides fault-tolerant high-speed links between switches,
routers, and servers. You can use it to increase the bandwidth between the wiring closets and the data
center, and you can deploy it anywhere in the network where bottlenecks are likely to occur.
EtherChannel provides automatic recovery for the loss of a link by redistributing the load across the
remaining links. If a link fails, EtherChannel redirects traffic from the failed link to the remaining links
in the channel without intervention.
Note For complete syntax and usage information for the commands used in this chapter, refer to the command
reference for this release.
This chapter consists of these sections:
• Understanding EtherChannels, page 27-1
• Configuring EtherChannels, page 27-8
• Displaying EtherChannel, PAgP, and LACP Status, page 27-19
Understanding EtherChannels
These sections describe how EtherChannels work:
• EtherChannel Overview, page 27-2
• Port-Channel Interfaces, page 27-3
• Port Aggregation Protocol, page 27-4
• Link Aggregation Control Protocol, page 27-5
• Load Balancing and Forwarding Methods, page 27-6

Cisco Catalyst 3750 Specifications

General

Device Type	Switch
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
RAM	128 MB
Jumbo Frame Support	Yes
Switch Type	Managed
Model	Catalyst 3750 Series
Uplink Interfaces	SFP
Form Factor	Rack-mountable
MAC Address Table Size	12, 000 entries
Routing Protocol	RIP, OSPF, EIGRP
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Layer 3 switching, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology
Power over Ethernet (PoE)	PoE
Operating Temperature	-5 - 45 °C
Operating Humidity	10% to 85% non-condensing
