24-15
Catalyst 3750 MetroSwitch Software Configuration Guide
78-15870-01
Chapter 24 Configuring SNMP
Displaying SNMP Status
This example shows how to send Entity MIB traps to the host cisco.com. The community string is
restricted. The first line enables the switch to send Entity MIB traps in addition to any traps previously
enabled. The second line specifies the destination of these traps and overwrites any previous
snmp-server host commands for the host cisco.com.
Switch(config)# snmp-server enable traps entity
Switch(config)# snmp-server host cisco.com restricted entity
This example shows how to enable the switch to send all traps to the host myhost.cisco.com using the
community string public:
Switch(config)# snmp-server enable traps
Switch(config)# snmp-server host myhost.cisco.com public
Displaying SNMP Status
To display SNMP input and output statistics, including the number of illegal community string entries,
errors, and requested variables, use the show snmp privileged EXEC command.You can also use the
other privileged EXEC commands in Table 24-5 to display SNMP information. For information about
the fields in the output displays, refer to the Cisco IOS Configuration Fundamentals Command
Reference for Release 12.1.
Note Though visible in the command-line help strings, the fru-ctrl keyword is not supported. The
snmp-server enable informs command is not supported. To enable the sending of SNMP inform
notifications, use the snmp-server enable traps command combined with the snmp-server host
host-addr informs command.
Table 24-5 Commands for Displaying SNMP Information
Feature Default Setting
show snmp Displays SNMP statistics.
show snmp engineID [local | remote] Displays information on the local SNMP engine and all
remote engines that have been configured on the device.
show snmp group Displays information on each SNMP group on the network.
show snmp user Displays information on each SNMP user name in the
SNMP users table.
