Cisco Catalyst 3750 Software Configuration Guide

29-4
Catalyst 3750 Metro Switch Software Configuration Guide
78-15870-01
Chapter 29 Configuring HSRP
Configuring HSRP
Default HSRP Configuration
Table 29-1 shows the default HSRP configuration.
HSRP Configuration Guidelines
Follow these guidelines when configuring HSRP:
• HSRP can be configured on a maximum of 32 VLAN or routing interfaces.
• In the following procedures, the specified interface must be one of these Layer 3 interfaces:
– Routed port: a physical port configured as a Layer 3 port by entering the no switchport
interface configuration command.
– SVI: a VLAN interface created by using the interface vlan vlan_id global configuration
command and by default a Layer 3 interface.
– Etherchannel port channel in Layer 3 mode: a port-channel logical interface created by using
the interface port-channel port-channel-number global configuration command and binding
the Ethernet interface into the channel group. For more information, see the “Configuring
Layer 3 EtherChannels” section on page 27-12.
• All Layer 3 interfaces must have IP addresses assigned to them. See the “Configuring Layer 3
Interfaces” section on page 9-18.
Table 29-1 Default HSRP Configuration
Feature Default Setting
HSRP groups None configured
Standby group number 0
Standby MAC address System assigned as: 0000.0c07.acXX, where XX is the HSRP
group number
Standby priority 100
Standby delay 0 (no delay)
Standby track interface priority 10
Standby hello time 3 seconds
Standby holdtime 10 seconds

Cisco Catalyst 3750 Specifications

General

Device Type	Switch
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
RAM	128 MB
Jumbo Frame Support	Yes
Switch Type	Managed
Model	Catalyst 3750 Series
Uplink Interfaces	SFP
Form Factor	Rack-mountable
MAC Address Table Size	12, 000 entries
Routing Protocol	RIP, OSPF, EIGRP
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Layer 3 switching, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology
Power over Ethernet (PoE)	PoE
Operating Temperature	-5 - 45 °C
Operating Humidity	10% to 85% non-condensing
