Chapter 29 Configuring HSRP
Configuring HSRP
Figure 29-1 Typical HSRP Configuration
Configuring HSRP
These sections include HSRP configuration information:
• Default HSRP Configuration, page 29-4
• HSRP Configuration Guidelines, page 29-4
• Enabling HSRP, page 29-5
• Configuring HSRP Group Attributes, page 29-6
Host B
172.20.130.5
172.20.128.32
Host A
172.20.128.55
172.20.128.1 172.20.128.3 172.20.128.2
Virtual
router
Active
router
Standby
router
Router A Router B
101361
Host C
