Cisco Catalyst 3750 Software Configuration Guide

29-9
Catalyst 3750 MetroSwitch Software Configuration Guide
78-15870-01
Chapter 29 Configuring HSRP
Configuring HSRP
Use the no standby [group-number] authentication string interface configuration command to delete
an authentication string. Use the no standby [group-number] timers hellotime holdtime interface
configuration command to restore timers to their default values.
This example shows how to configure word as the authentication string required to allow Hot Standby
routers in group 1 to interoperate:
Switch# configure terminal
Switch(config)# interface gigabitethernet1/0/1
Switch(config-if)# no switchport
Switch(config-if)# standby 1 authentication word
Switch(config-if)# end
Switch#
This example shows how to set the timers on standby group 1 with the time between hello packets at 5
seconds and the time after which a router is considered down to be 15 seconds:
Switch# configure terminal
Switch(config)# interface gigabitethernet1/0/1
Switch(config-if)# no switchport
Switch(config-if)# standby 1 ip
Switch(config-if)# standby 1 timers 5 15
Switch(config-if)# end
Switch#
Step 4
standby [group-number] timers hellotime
holdtime
(Optional) Configure the time between hello packets and the
time before other routers declare the active router to be down.
• group-number—The group number to which the command
applies.
• hellotime—The hello interval in seconds. The range is from
1 to 255; the default is 3 seconds.
• holdtime—The time in seconds before the active or standby
router is declared to be down. The range is from 1 to 255;
the default is 10 seconds.
Step 5
end Return to privileged EXEC mode.
Step 6
show running-config Verify the configuration of the standby groups.
Step 7
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose

Cisco Catalyst 3750 Specifications

General

Device Type	Switch
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
RAM	128 MB
Jumbo Frame Support	Yes
Switch Type	Managed
Model	Catalyst 3750 Series
Uplink Interfaces	SFP
Form Factor	Rack-mountable
MAC Address Table Size	12, 000 entries
Routing Protocol	RIP, OSPF, EIGRP
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Layer 3 switching, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology
Power over Ethernet (PoE)	PoE
Operating Temperature	-5 - 45 °C
Operating Humidity	10% to 85% non-condensing
