Cisco Catalyst 3750 Software Configuration Guide

4-7
Catalyst 3750 MetroSwitch Software Configuration Guide
78-15870-01
Chapter 4 Configuring IE2100 CNS Agents
Configuring CNS Embedded Agents
Note For more information about running the setup program and creating templates on the Configuration
Registrar, refer to the Cisco Intelligence Engine 2100 Series Configuration Registrar Manual.
DHCP server
• IP address assignment
• TFTP server IP address
• Path to bootstrap configuration file on the TFTP server
• Default gateway IP address
TFTP server
• Create a bootstrap configuration file that includes the CNS
configuration commands that enable the switch to
communicate with the IE2100 Configuration Registrar.
• Configure the switch to use either the switch MAC address or
the serial number (instead of the default host name) to
generate the configID and eventID.
• Configure the CNS event agent to push the configuration file
to the switch.
IE2100 Configuration Registrar Create one or more templates for each type of device, and map the
configID of the device to the template.
Table 4-1 Prerequisites for Enabling Automatic Configuration (continued)
Device Required Configuration

Cisco Catalyst 3750 Specifications

General

Device Type	Switch
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
RAM	128 MB
Jumbo Frame Support	Yes
Switch Type	Managed
Model	Catalyst 3750 Series
Uplink Interfaces	SFP
Form Factor	Rack-mountable
MAC Address Table Size	12, 000 entries
Routing Protocol	RIP, OSPF, EIGRP
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Layer 3 switching, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology
Power over Ethernet (PoE)	PoE
Operating Temperature	-5 - 45 °C
Operating Humidity	10% to 85% non-condensing
