Cisco RV110W Administration Guide

Configuring VPN
Configuring Advanced VPN Parameters
Cisco RV110W Administration Guide 102
5
Configuring Advanced VPN Parameters
The Advanced VPN Setup page allows you to configure advanced VPN
parameters, such as IKE and other VPN policies. These policies control how the
Cisco RV110W initiates and receives VPN connections with other endpoints.
Managing IKE Policies
The Internet Key Exchange (IKE) protocol dynamically exchanges keys between
two IPsec hosts. You can create IKE policies to define the security parameters
such as authentication of the peer, encryption algorithms, etc. to be used in this
process. Be sure to use compatible encryption, authentication, and key-group
parameters for the VPN policy.
To manage IKE policies:
STEP 1 Choose VPN > IPsec > Advanced VPN Setup.
STEP 2 In the IKE Policy Table, checking the box in the VPN connection row allows you to
perform the following tasks:
• Edit—Edit properties of the IKE policy. See Adding or Editing IKE Policies.
• Enable—Enable the policy.
• Disable—Disable the policy.
• Delete—Delete the policy. (Note: You cannot delete an IKE policy if it is being
used in a VPN policy. You must first disable and delete the VPN policy in the
VPN Policy table.)
• Add Row—Add an IKE policy. See Adding or Editing IKE Policies. (Note: If
you have a VPN connection already configured, you cannot add another
without deleting the existing VPN connection.)
STEP 3 Click Save.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
