Cisco RV110W Administration Guide

Administering Your Cisco RV110W
Configuring Logging
Cisco RV110W Administration Guide 124
7
Configuring Port Mirroring
Port mirroring monitors network traffic by sending copies of all incoming and
outgoing packets from one port to a monitoring port. You can use port mirroring as
a diagnostic or debugging tool, especially when fending off an attack or viewing
user traffic from LAN to WAN to see if users are accessing information or websites
they are not supposed to.
The LAN host (PC) should use a static IP address to avoid any issues with port
mirroring. DHCP leases can expire for a LAN host and can cause port mirroring to
fail so if a static IP address is not configured for the LAN host.
To configure port mirroring:
STEP 1 Choose Administration > Diagnostics > Port Mirroring.
STEP 2 In the Mirror Source field, select the ports to mirror.
STEP 3 From the Mirror Port drop-down menu, choose a mirror port. If you use a port for
mirroring, do not use it for any other traffic.
STEP 4 Click Save.
Configuring Logging
The Cisco RV110W allows you to configure logging options.
Configuring Logging Settings
To configure logging:
STEP 1 Choose Administration > Logging > Log Settings.
STEP 2 In the Log Mode field, check Enable.
STEP 3 Click Add Row.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
