Cisco RV110W Administration Guide

Configuring Networking
Configuring IPv6
Cisco RV110W Administration Guide 56
2
Configuring Router Advertisement
The Router Advertisement Daemon (RADVD) on the Cisco RV110W listens for
router solicitations in the IPv6 LAN and responds with router advertisements as
required. This is stateless IPv6 auto configuration, and the Cisco RV110W
distributes IPv6 prefixes to all nodes on the network.
To configure the RADVD:
STEP 1 Choose Networking > IPv6 > Router Advertisement.
STEP 2 Enter this information:
RADVD Status Check Enable to enable RADVD.
Advertise Mode Select one of the following modes:
Unsolicited Multicast—Select this mode to send
Router Advertisements (RAs) to all interfaces
belonging to the multicast group.
Unicast only—Select this mode to restrict
advertisements to well-known IPv6 addresses only
(RAs are sent to the interface belonging to the
known address only).
Advertise Interval If you choose Unsolicited Multicast as the
advertise mode, enter the advertise interval
(4–1800). The default is 30. The advertise interval is
a random value between the Minimum Router
Advertisement Interval (MinRtrAdvInterval) and
Maximum Router Advertisement Interval
(MaxRtrAdvInterval).
MinRtrAdvInterval = 0.33 * MaxRtrAdvInterval
RA Flags Check Managed to use the administered/stateful
protocol for address auto configuration.
Check Other to use the administered/stateful
protocol of other, non-address information auto
configuration.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
