Cisco RV110W Administration Guide

Configuring Networking
Configuring IPv6
Cisco RV110W Administration Guide 45
2
STEP 3 (Optional) If you are using 6to4 tunneling, which allows IPv6 packets to be
transmitted over an IPv4 network, do the following:
a. Click Show Static 6to4 DNS Entry.
b. In the Domain and IP fields, enter up to five domain-to-IP mappings.
The 6to4 tunneling feature is typically used when a site or end user wants to
connect to the IPv6 Internet using the existing IPv4 network.
STEP 4 Click Save.
Configuring IPv6
Internet Protocol version 6 (IPv6) is a version of the Internet Protocol (IP) intended
to succeed Internet Protocol version 4 (IPv4). Configuring WAN properties for an
IPv6 network depends on the type of internet connection that you have.
Configuring the WAN for an IPv6 Network
You can configure the Cisco RV110W to be a DHCPv6 client of the ISP for this
WAN or to use a static IPv6 address provided by the ISP.
Setting the IP Mode
To configure IPv6 WAN settings on your Cisco RV110W, you must first set the IP
mode to LAN:IPv6, WAN:IPv6 or LAN:IPv4+IPv6, WAN:IPv4+IPv6.
See Configuring the IP Mode for more information.
LAN:IPv6, WAN:IPv6 Choose this option to use IPv6 in the LAN and WAN
ports.
LAN:IPv4+IPv6,
WAN:IPv4
Choose this option to use IPv4 and IPv6 in the LAN
ports and IPv4 in the WAN ports.
LAN:IPv4+IPV6,
WAN:IPv4+IPv6
Choose this option to use IPv4 and IPv6 in both the
LAN and WAN ports.
LAN:IPv4, WAN:IPv6 Choose this option to use IPv4 in the LAN and IPv6
in the WAN ports.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
