Cisco RV110W Administration Guide

Introduction
Getting to Know the Cisco RV110W
Cisco RV110W Administration Guide 12
1
Back Panel
RESET If the Cisco RV110W has problems connecting to
the Internet, press the RESET button for at least 3
but no more than 10 seconds with a paper clip or
similar object. This is similar to pressing the reset
button on your PC to reboot it.
If you are experiencing extreme problems with the
Cisco RV110W and have tried all other
troubleshooting measures, press and hold in the
RESET button for more than 10 seconds. This
reboots the unit and restores the factory defaults.
Changes you have previously made to the
Cisco RV110W settings are lost.
LAN (1–4) LAN connections to network devices, such as PCs,
print servers, or switches.
WAN The WAN (Internet) port is connected to your
Internet device, such as a cable or DSL modem.
POWER Press to turn the Cisco RV110W on or off.
12VDC Connect the provided 12V AC power adapter to
the 12VDC port.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
