Cisco RV110W Administration Guide

Introduction
Getting to Know the Cisco RV110W
Cisco RV110W Administration Guide 10
1
Virtual Networks
The Cisco RV110W also supports multiple Service Set Identifiers (SSIDs) for the
use of virtual networks (up to four separate virtual networks), with 802.1Q-based
VLAN support for traffic separation.
Configuration and Administration
With the Cisco RV110W embedded web server, you can configure the
Cisco RV110W settings using the browser-based Device Manager. The
Cisco RV110W supports Internet Explorer, Firefox, and Safari web browsers.
The Cisco RV110W also provides a Setup Wizard that allows you to easily and
quickly configure the Cisco RV110W basic settings.
Getting to Know the Cisco RV110W
Front Panel
Power The Power light is green to indicate the unit is powered
on. The light flashes green when the power is coming
on.
WPS The Wi-Fi Protected Setup (WPS) button is used to
configure wireless access for devices in your network
that are WPS-enabled. See Configuring WPS, page 77
for more information.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
