Cisco RV110W Administration Guide

Configuring the Wireless Network
Configuring Basic Wireless Settings
Cisco RV110W Administration Guide 66
3
Configuring the Security Mode
You can configure one of the following security modes for wireless networks:
Configuring WEP
The WEP security mode offers weak security with a basic encryption method that
is not as secure as WPA. WEP may be required if your network devices do not
support WPA.
NOTE If you do not have to use WEP, we recommend that you use WPA2. If you are using
the Wireless-N only mode, you must use WPA2.
To configure the WEP security mode:
STEP 1 In the Wireless Table (Wireless > Basic Settings), check the box for the network
you want to configure.
STEP 2 Click Edit Security Mode.
The Security Settings page appears.
STEP 3 In the Select SSID field, choose the SSID for which to configure the security
settings.
STEP 4 From the Security Mode menu, choose WEP.
STEP 5 In the Authentication Type field, choose one of the following options:
• Open System—This is the default option.
• Shared Key—Select this option if your network administrator recommends
this setting. If you are unsure, select the default option.
In both cases, the wireless client must provide the correct shared key (password)
to access the wireless network.
STEP 6 In the Encryption field, choose the encryption type:
• 10/64-bit(10 hex digits)—Provides a 40-bit key.
• 26/128-bit(26 hex digits)—Provides a a 104-bit key, which offers stronger
encryption, making the key more difficult to crack. We recommend 128-bit
encryption.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
