Cisco RV110W Administration Guide

Configuring the Wireless Network
Configuring WDS
Cisco RV110W Administration Guide 76
3
Configuring WDS
A Wireless Distribution System (WDS) is a system that enables the wireless
interconnection of access points in a network. It allows a wireless network to be
expanded using multiple access points without the need for a wired backbone to
link them.
To establish a WDS link, the Cisco RV110W and other remote WDS peers must be
configured in the same wireless network mode, wireless channel, wireless band
selection, and encryption types (None and WEP).
NOTE WDS is supported on one SSID only.
To configure a WDS:
STEP 1 Choose Wireless > WDS.
STEP 2 Check the Allow wireless signal to be repeated by a repeater box to enable
WDS.
STEP 3 To manually enter the MAC address of a repeater, click the Manual button, or
choose Auto to have the router automatically detect the remote access points.
STEP 4 (Optional) Click the Show Site Survey button.
The Available Networks Table appears listing the available wireless network
access points.
a. (Optional) Click the Refresh button to update the entries in the table.
b. In the Available Networks Table, select up to three access points to use as
repeaters.
c. To add the MAC addresses of the selected access points to the MAC fields
below the table, click Connect.
STEP 5 If you clicked the Manual button, enter the MAC addresses of up to three access
points to use as repeaters in the MAC 1, MAC 2, and MAC 3 fields.
STEP 6 Click Save.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
