Cisco RV110W Administration Guide

Configuring Networking
Configuring the LAN Settings
Cisco RV110W Administration Guide 34
2
Configuring Static DHCP
You can configure the Cisco RV110W to assign a specific IP address to a device
with a specific MAC address.
To configure static DHCP:
STEP 1 Choose Networking > LAN > Static DHCP.
STEP 2 From the VLAN drop-down menu, choose a VLAN number.
STEP 3 Click Add Row.
STEP 4 Enter this information:
To edit the settings of a static DHCP client, select the client and click Edit. To
delete a selected DHCP client, click Delete. Click Save to apply changes.
Description Enter a description of the client.
IP Address Enter the IP address of the device.
The IP address assigned should be outside the
pool of the DHCP addresses configured. The DHCP
pool is treated as a generic pool and all reserved IP
addresses should be outside this pool.
Static DHCP assignment means the DHCP server
assigns the same IP to the defined MAC address
every time the device is connected to the network.
The DHCP server serves the reserved IP address
when the device using the corresponding MAC
address requests an IP address.
MAC Address Enter the MAC address of the device.
The format for the MAC Address is
XX:XX:XX:XX:XX:XX where X is a number from 0 to
9 (inclusive) or an alphabetical letter between A
and F (inclusive).

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
