Cisco RV110W Administration Guide

Viewing the Cisco RV110W Status
Viewing the GuestNet Status
Cisco RV110W Administration Guide 147
8
Viewing the GuestNet Status
The guest network statistics displays information about the wireless guest
network configured on the Cisco RV110W. To view the guest network status,
choose Status > GuestNet Status. The following information is displayed:
• Host Name—Device connected to the guest network.
• IP Address—IP address assigned to the connected device.
• MAC Address—MAC or hardware address of the connected device.
• Time Left—Remaining time that the device can be connected to the guest
network. (Time limits are configured in the Wireless > Basic Settings >
Guest Net Settings page.)
• Action—Actions you can perform on the connected device (for example,
disconnect).
Multicast The number of multicast packets sent over this radio.
Collisions The number of signal collisions that occurred on this port.
A collision occurs when the port tries to send data at the
same time as a port on another router or computer that is
connected to this port.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
