Cisco RV110W Administration Guide

Configuring the Firewall
Configuring Access Rules
Cisco RV110W Administration Guide 86
4
To create a custom service:
STEP 1 Choose Firewall > Service Management.
STEP 2 Click Add Row.
STEP 3 In the Service Name field, enter the service name for identification and
management purposes.
STEP 4 In the Protocol field, choose the Layer 4 protocol that the service uses from the
drop-down menu:
• TCP
• UDP
• TCP & UDP
• ICMP
STEP 5 In the Start Port field, enter the first TCP or UDP port of the range that the service
uses.
STEP 6 In the End Port field, enter the last TCP or UDP port of the range that the service
uses.
STEP 7 Click Save.
To edit an entry, select the entry and click Edit. Make your changes, then click
Save.
Configuring Access Rules
Configuring the Default Outbound Policy
The Access Rules page allows you to configure the default outbound policy for
the traffic that is directed from the secure network (LAN) to the non-secure
network (dedicated WAN/optional).
The default inbound policy for traffic flowing from the non-secure zone to the
secure zone is always blocked and cannot be changed.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
