Cisco RV110W Administration Guide

Administering Your Cisco RV110W
Backing Up and Restoring the System
Cisco RV110W Administration Guide 129
7
STEP 2 Configure this information:
STEP 3 Click Save.
Backing Up and Restoring the System
You can back up custom configuration settings for later restoration or restore from
a previous backup from the Administration > Backup / Restore Settings page.
When the firewall is working as configured, you can back up the configuration for
restoring later. During backup, your settings are saved as a file on your PC. You can
restore the firewall settings from this file.
Time Zone Select your time zone, relative to Greenwich Mean
Time (GMT).
Adjust for Daylight
Savings Time
If supported for your region, check the Adjust for
Daylight Savings Time box.
This check box is enabled if you click Auto in the
Set Date and Time field below.
Daylight Saving Mode Choose either By date (you enter the specific date
on which daylight saving mode starts) or Recurring
(you enter the month, week, day of week, and time
on which daylight saving time starts). Enter the
appropriate information in the “from” and “to” fields.
Daylight Saving Offset Choose the offset from Coordinated Universal
Time (UTC) from the drop-down menu.
Set Date and Time Select how to set the date and time.
NTP Server To use the default NTP servers, click the Use
Default button.
To use a specific NTP server, click the User
Defined NTP Server and enter the fully-qualified
domain name or IP address of the NTP servers in
the two available fields.
Enter Date and Time Enter the date and time.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
