Cisco RV110W Administration Guide

Configuring Networking
Configuring Routing
Cisco RV110W Administration Guide 40
2
Configuring Routing
Configure the routing options.
Configuring the Operating Mode
To configure the Cisco RV110W operating mode:
STEP 1 Choose Networking > Routing.
STEP 2 In the Operating Mode field, select one of the following options:
STEP 3 Click Save.
Configuring Dynamic Routing
Routing Information Protocol (RIP) is an Interior Gateway Protocol (IGP) that is
commonly used in internal networks. It allows the router to exchange its routing
information automatically with other routers, and allows it to dynamically adjust its
routing tables and adapt to changes in the network.
Dynamic Routing (RIP) enables the Cisco RV110W to automatically adjust to
physical changes in the network layout and exchange routing tables with the other
routers.
Gateway (Recommended) Click this button to set the
Cisco RV110W to act as a gateway.
Keep this default setting if the Cisco RV110W is
hosting your network connection to the Internet
and is performing the routing functions.
Router (For advanced users only) Click this button to set
the Cisco RV110W to act as a router.
Select this option if the Cisco RV110W is on a
network with other routers.
Enabling the Router mode disables NAT (Network
Address Translation) on the Cisco RV110W.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
