Cisco RV110W Administration Guide

Configuring Networking
Configuring the LAN Settings
Cisco RV110W Administration Guide 37
2
STEP 3 In the Setting Table, configure the following settings:
STEP 4 Click Save.
Port Management
You can configure the speed and flow control settings of the Cisco RV110W LAN
ports.
To configure port speeds and flow control:
STEP 1 Choose Networking > Port Management.
Forward Delay The forward delay is the interval after which an
interface changes from the blocking to forwarding
state. Enter a number from 4 to 30. The default is
15.
Force Version Select the default protocol version to use. Select
Normal (use RSTP) or Compatible (compatible
with old STP). The default is Normal.
Protocol Enable Check to enable RSTP on the associated port.
RSTP is disabled by default.
Edge Check to specify that the associated port is an
edge port (end station). Uncheck to specify that the
associated port is a link (bridge) to another STP
device. Edge port is enabled by default.
Path Cost Enter the RSTP path cost for the designated ports.
Use 0 for the default value (the Cisco RV110W
automatically determines the path value). You can
also enter a number from 2 to 200000000.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
