Cisco RV110W Administration Guide

Configuring Networking
Cloning the MAC Address
Cisco RV110W Administration Guide 39
2
Cloning the MAC Address
Sometimes, you may need to set the MAC address of the Cisco RV110W WAN
port to be the same MAC address as your PC or some other MAC address. This is
called MAC address cloning.
For example, some ISPs register your computer NIC card MAC address when the
service is first installed. When you place a router behind the cable modem or DSL
modem, the MAC address from the Cisco RV110W WAN port is not recognized by
the ISP.
In this case, to configure your Cisco RV110W to be recognized by the ISP, clone
the MAC address of the WAN port to be the same as your computer MAC address.
To configure a MAC address clone:
STEP 1 Choose Networking > MAC Address Clone.
STEP 2 In the MAC Address Clone field, check Enable to enable MAC address cloning.
STEP 3 To set the MAC address of the Cisco RV110W WAN port, do one of the following:
• To set the MAC address of the WAN port to your PC MAC address, click
Clone My PC’s MAC.
• To specify a different MAC address, enter it in the MAC Address field.
STEP 4 Click Save.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
