Cisco RV110W Administration Guide

Configuring the Wireless Network
Configuring Basic Wireless Settings
Cisco RV110W Administration Guide 69
3
STEP 3 In the Select SSID field, choose the SSID for which to configure the security
settings.
STEP 4 From the Security Mode menu, choose one of the three WPA Enterprise options.
STEP 5 (WPA-Enterprise only) In the Encryption field, choose one of the following options:
• TKIP/AES—Choose TKIP/AES to ensure compatibility with older wireless
devices that may not support AES.
• AES—This option is more secure.
STEP 6 In the RADIUS Server field, enter the IP address of the RADIUS server.
STEP 7 In the RADIUS Port field, enter the port used to access the RADIUS server.
STEP 8 In the Shared Key field, enter an alphanumeric phrase (8–63 ASCII characters or
64 hexadecimal digits).
STEP 9 In the Key Renewal field, enter the duration of time (600–7200 seconds) between
key renewals. The default value is 3600.
STEP 10 Click Save to save your settings.
STEP 11 Click Back to go back to the Basic Settings page.
Configuring MAC Filtering
You can use MAC Filtering to permit or deny access to the wireless network based
on the MAC (hardware) address of the requesting device. For example, you can
enter the MAC addresses of a set of computers and only allow those computers to
access the network. You can configure MAC Filtering for each network or SSID.
To configure MAC filtering:
STEP 1 In the Wireless Table (Wireless > Basic Settings), check the box for the network
you want to configure.
STEP 2 Click Edit MAC Filtering. The Wireless MAC Filter page appears.
STEP 3 In the Edit MAC Filtering field, check the Enable box to enable MAC Filtering for
this SSID.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
