Cisco RV110W Administration Guide

Introduction
Connecting to Your Wireless Network
Cisco RV110W Administration Guide 21
1
Connecting to Your Wireless Network
To connect a device (such as a computer) to your wireless network, configure the
wireless connection on the device with the wireless security information you
configured for the Cisco RV110W by using the Setup Wizard.
The following steps are provided as an example; you may need to configure your
device differently. For instructions that are specific to your device, consult its
documentation.
STEP 1 Open the wireless connection settings window or program for your device.
Your computer may have special software installed to manage wireless
connections, or you may find wireless connections under the Control Panel in the
Network Connections or Network and Internet window. (The location depends
on your operating system.)
STEP 2 Enter the network name (SSID) you chose for your network in the Setup Wizard.
STEP 3 Choose the type of encryption and enter the security key that you specified in the
Setup Wizard.
If you did not enable security (not recommended), leave the wireless encryption
fields that were configured with the security type and passphrase blank.
STEP 4 Verify your wireless connection and save your settings.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
