Cisco RV110W Administration Guide

Administering Your Cisco RV110W
Configuring Simple Network Management (SNMP)
Cisco RV110W Administration Guide 121
7
STEP 3 Click Save.
Configuring the SNMP Traps
The fields in the SNMP Trap Configuration section allow you to configure an
SNMP agent to which the firewall sends trap messages (notifications).
To configure the traps:
STEP 1 Choose Administration > SNMP.
STEP 2 Under Trap Configuration, configure the following settings:
Security Level Choose the SNMPv3 security level:
No Authentication and No Privilege—Doesn't
require any Authentication and Privacy.
Authentication and No Privilege—Submit only
Authentication algorithm and password.
Authentication and Privilege—Submit
Authentication/privacy algorithm and password.
Authentication
Algorithm Server
Select the type of authentication algorithm (MD5 or
SHA).
Authentication
Password
Enter the authentication password.
Privacy Algorithm Choose the type of privacy algorithm (DES or AES).
Privacy Password Enter the privacy password.
IP Address Enter the IP address of the SNMP manager or trap
agent.
Port Enter the SNMP trap port of the IP address to
which the trap messages will be sent.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
