Cisco RV110W Administration Guide

Configuring Networking
Configuring the IP Mode
Cisco RV110W Administration Guide 44
2
STEP 5 To test the DDNS configuration, click Test Configuration.
STEP 6 Click Save.
Configuring the IP Mode
Wide area network configuration properties are configurable for both IPv4 and
IPv6 networks. You can enter information about your Internet connection type and
other parameters in these pages.
To select an IP mode:
STEP 1 Choose Networking > IP Mode.
STEP 2 From the IP Mode drop-down menu, choose one of the following options:
Password Enter the password of the DDNS account.
Verify Password (TZO.com, DynDNS.com, and noip.com) Reenter
the password of the DDNS account.
Host Name (DynDNS.com, 3322.org, and noip.com) Enter the
host name of the DDNS server.
Domain Name (TZO.com) Enter the name of the domain that is
used to access the network.
Internet IP Address (Read-only) The Internet IP address of the
Cisco RV110W.
Status (Read-only) Status is displayed if the DDNS update
has completed successfully or if the account
update information sent to the DDNS server failed.
LAN:IPv4, WAN:IPv4 Choose this option to use IPv4 in the LAN and WAN
ports.
LAN:IPv6, WAN:IPv4 Choose this option to use IPv6 in the LAN ports and
IPv4 in the WAN ports.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
