Cisco RV110W Administration Guide

Configuring VPN
Configuring Advanced VPN Parameters
Cisco RV110W Administration Guide 103
5
Managing VPN Policies
To manage VPN policies:
STEP 1 Choose VPN > IPsec > Advanced VPN Setup.
STEP 2 In the VPN Policy Table, checking the box in the VPN connection row allows you to
perform the following tasks:
• Edit—Edit properties of the VPN policy. See Adding or Editing VPN
Policies.
• Enable—Enable the policy.
• Disable—Disable the policy.
• Delete—Delete the policy.
• Add Row—Add a VPN policy. See Adding or Editing VPN Policies. (Note: If
you have a VPN connection already configured, you cannot add another
without deleting the existing VPN connection.)
STEP 3 Click Save.
Adding or Editing IKE Policies
When adding or editing IKE policies, configure the following settings:
• Policy Name—Enter a unique name for the policy for identification and
management purposes.
• Exchange Mode—Choose one of the following options:
- Main—This mode negotiates the tunnel with higher security, but is
slower.
- Aggressive—This mode establishes a faster connection, but with
lowered security.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
