Cisco RV110W Administration Guide

Configuring Networking
Configuring the WAN Settings
Cisco RV110W Administration Guide 23
2
STEP 3 (Optional) To configure the optional settings, see Configuring Optional Settings.
STEP 4 Click Save.
Configuring Static IP
If your ISP assigned you a permanent IP address, perform the following steps to
configure your WAN settings:
STEP 1 Choose Networking > WAN.
STEP 2 From the Internet Connection Type drop-down menu, choose Static IP.
STEP 3 Enter this information:
STEP 4 (Optional) To configure the optional settings, see Configuring Optional Settings.
STEP 5 Click Save.
Configuring PPPoE
To configure the PPPoE settings:
STEP 1 Choose Networking > WAN.
STEP 2 From the Internet Connection Type drop-down menu, choose PPPoE.
STEP 3 Enter the following information (you may need to contact your ISP to obtain your
PPPoE login information):
Internet IP Address Enter the IP address of the WAN port.
Subnet mask Enter subnet mask of the WAN port.
Default Gateway Enter the IP address of the default gateway.
Static DNS 1 Enter the IP address of the primary DNS server.
Static DNS 2 Enter the IP address of the secondary DNS server.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
