Cisco RV110W Administration Guide

Viewing the Cisco RV110W Status
Viewing Connected Devices
Cisco RV110W Administration Guide 145
8
• Warning—System warning occurred.
• Notification—System is functioning properly, but a system notice occurred.
• Informational—Device information.
• Debugging—Provides detailed information about an event.
To delete all entries in the log window, click Clear Logs.
To save all log messages from the firewall to the local hard drive, click Save Logs.
To specify the number of entries to show per page, choose a number from the
drop-down menu.
Use the page navigation buttons to move between log pages.
Viewing Connected Devices
The Connected Devices page displays information about the active devices
connected to the Cisco RV110W.
The IPv4 ARP Table displays information from devices that have responded to the
Cisco RV110W address resolution protocol (ARP) request. If a device does not
respond to the request, it is removed from the list.
The IPv6 NDP Table displays all IPv6 neighbor discover protocol (NDP) devices
connected to the Cisco RV110W local link.
To view connected devices:
STEP 1 Choose Status > Connected Devices.
STEP 2 In the IPv4 ARP Table, you can specify the types of interfaces to display by
selecting an option from the Filter drop-down menu. You can choose one of the
following options:
All Displays a list of all devices connected to the
router.
Wireless Displays a list of all devices connected through the
wireless interface.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
