Cisco RV110W Administration Guide

Viewing the Cisco RV110W Status
Viewing the System Summary
Cisco RV110W Administration Guide 139
8
VPN
• QuickVPN Users—The number of QuickVPN users.
• PPTP Users—The number of Point-to-Point Tunneling Protocol (PPTP)
users.
Viewing the System Summary
The System Summary page displays a summary of the router settings.
To view a summary of system settings:
STEP 1 Choose Status > System Summary.
STEP 2 Click Refresh to obtain the latest information.
The System Summary page displays this information:
System Information
• Firmware Version—Current software version the device is running.
• Firmware MD5 Checksum—The message-digest algorithm used to verify
the integrity of files.
• Locale—The language installed on the router.
• Language Version—The version of the installed language pack. The
language pack version should be compatible with the currently- installed
firmware. In some cases, an older language pack may be used with a newer
firmware image. The router will check the language pack version to see if it
is compatible with the current firmware version.
• Language MD5 Checksum—The MD5 checksum of the language pack.
• CPU Model—Chipset of CPU currently used.
• Serial Number—Serial number of the device.
• System Up Time—How long the system has been running.
• Current Time—Time of day.
• PID VID—Product ID and version ID of the device.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
