Cisco RV110W Administration Guide

Configuring Quality of Service (QoS)
Configuring Bandwidth Management
Cisco RV110W Administration Guide 112
6
STEP 3 In the Bandwidth Table, enter the following information for the WAN interface:
STEP 4 Click Save.
Configuring Bandwidth Priority
In the Bandwidth Priority Table, you can assign priorities to services to manage
bandwidth usage.
To configure bandwidth priority:
STEP 1 Choose QoS > Bandwidth Management.
STEP 2 In the Bandwidth Management field, check Enable. The maximum bandwidth
provided by your ISP appears in the Bandwidth section.
STEP 3 In the Bandwidth Priority Table, click Add Row.
STEP 4 Enter this information:
STEP 5 Click Save.
To edit the settings of an entry in the table, check the relevant box and click Edit.
When you are done making changes, click Save.
Upstream The bandwidth (kb/s) used for sending data to the
Internet.
Downstream The bandwidth (kb/s) used for receiving data from
the Internet.
Enable Check to enable bandwidth management for this
service.
Service Choose the service to prioritize.
Direction Choose the direction of the traffic you want to
prioritize (downstream or upstream).
Priority Choose the priority of the service (low, normal,
medium, or high).

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
