Cisco RV110W Administration Guide

Viewing the Cisco RV110W Status
Viewing the Wireless Statistics
Cisco RV110W Administration Guide 141
8
• SSID 4—The public name of the fourth wireless network.
- Security—The security setting for SSID 4.
Firewall Setting Status
• Dos (Denial of Service)—Whether DoS prevention is on or off.
• Block WAN Request—Whether WAN request blocking is on or off.
• Remote Management—Whether remote management is on or off (for
example, if the Cisco RV110W Device Manager can be accessed remotely).
VPN Setting Status
• QuickVPN Connections Available—The number of available QuickVPN
connections.
• PPTP VPN Connections Available—The number of available PPTP VPN
connections.
• Connected QuickVPN Users—The number of connected QuickVPN users.
• Connected PPTP VPN Users—The number of connected PPTP VPN
users.
Viewing the Wireless Statistics
The Wireless Statistics page shows a cumulative total of relevant wireless
statistics for the radio on the device.
To v i e w w i r e l e s s s t a t i s t i c s :
STEP 1 Choose Status > Wireless Statistics.
STEP 2 From the Refresh Rate drop-down menu, choose a refresh rate.
STEP 3 (Optional) By default, byte data is displayed in bytes and other numerical data is
displayed in long form. To show the bytes in kilobytes (KB) and the numerical data
in rounded up form, check Show Simplified Statistic Data and click Save.
STEP 4 To reset the wireless statistics counters, click Clear Count.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
