Cisco RV110W Administration Guide

Configuring the Wireless Network
Configuring Advanced Wireless Settings
Cisco RV110W Administration Guide 75
3
STEP 3 Click Save.
DTIM Interval This value, between 1 and 255, indicates the interval of
the Delivery Traffic Indication Message (DTIM). A DTIM
field is a countdown field informing clients of the next
window for listening to broadcast and multicast
messages.
When the Cisco RV110W has buffered broadcast or
multicast messages for associated clients, it sends the
next DTIM with a DTIM Interval value. Its clients hear the
beacons and awaken to receive the broadcast and
multicast messages. The default value is 1.
Fragmentation
Threshold
This value specifies the maximum size for a packet
before data is fragmented into multiple packets. If you
experience a high packet error rate, you may slightly
increase the Fragmentation Threshold.
Setting the Fragmentation Threshold too low may result
in poor network performance. Only minor reduction of
the default value is recommended. In most cases, it
should remain at its default value of 2346.
RTS Threshold If you encounter inconsistent data flow, enter only minor
reductions. The default value of 2347 is recommended.
If a network packet is smaller than the preset Request to
Send (RTS) threshold size, the RTS/Clear to Send (CTS)
mechanism will not be enabled. The Services Ready
Platform sends RTS frames to a particular receiving
station and negotiates the sending of a data frame.
After receiving an RTS, the wireless station responds
with a CTS frame to acknowledge the right to begin
transmission.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
