Cisco RV110W Administration Guide

Configuring the Wireless Network
Configuring Advanced Wireless Settings
Cisco RV110W Administration Guide 74
3
Transmission Rate The rate of data transmission should be set depending
on the speed of your wireless network. You can select
from a range of transmission speeds, or you can select
Auto to have the Cisco RV110W automatically use the
fastest possible data rate and enable the Auto-Fallback
feature. Auto-Fallback will negotiate the best possible
connection speed between the Cisco RV110W and a
wireless client. The default is Auto.
N Transmission
Rate
The rate of data transmission should be set depending
on the speed of your Wireless-N networking. You can
select from a range of transmission speeds, or you can
select Auto to have the Cisco RV110W automatically
use the fastest possible data rate and enable the Auto-
Fallback feature. Auto-Fallback will negotiate the best
possible connection speed between the Cisco RV110W
and a wireless client. The default is Auto.
CTS Protection
Mode
The Cisco RV110W will automatically use CTS (Clear-To-
Send) Protection Mode when your Wireless-N and
Wireless-G devices are experiencing severe problems
and are not able to transmit to the Cisco RV110W in an
environment with heavy 802.11b traffic.
This function boosts the Cisco RV110W ability to catch
all Wireless-N and Wireless-G transmissions but will
severely decrease performance. The default is Auto.
Beacon Interval The Beacon Interval value indicates the frequency
interval of the beacon. A beacon is a packet broadcast
by the Cisco RV110W to synchronize the wireless
network.
Enter a value between 40 and 3,500 milliseconds. The
default value is 100.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
