Cisco RV110W Administration Guide

Introduction
Getting to Know the Cisco RV110W
Cisco RV110W Administration Guide 11
1
WAN The WAN (Internet) light is green when the
Cisco RV110W is connected to the Internet through
your cable or DSL modem. The light is off when the
Cisco RV110W is not connected to the Internet. The
light flashes green when it is sending or receiving data
Wireless The Wireless light is green when the wireless module is
enabled. The light is off when the wireless module is
disabled. The light flashes green when the firewall is
transmitting or receiving data on the wireless module.
LAN Ports The numbered lights correspond to the LAN ports on
the Cisco RV110W.
If the lights are continuously green, the Cisco RV110W
is connected to a device through the corresponding
port (1, 2, 3, or 4). The light for a port flashes green when
the firewall is actively sending or receiving data over
that port.
Power The Power light is green to indicate the unit is powered
on. The light flashes green when the power is coming
on.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
