Cisco RV110W Administration Guide

Configuring Networking
Configuring IPv6
Cisco RV110W Administration Guide 46
2
Configuring DHCPv6
If your ISP provides you with a dynamically-assigned address, configure the
Cisco RV110W to use be a DHCPv6 client.
To configure the Cisco RV110W to be a DHCPv6 client:
STEP 1 Choose Networking > IPv6 > IPv6 WAN Configuration.
STEP 2 In the WAN Connection Type field, select Automatic Configuration-DHCPv6.
STEP 3 Click Save.
Configuring a Static WAN IP Address
If your ISP assigns you a fixed address to access the Internet, configure the
Cisco RV110W to use a static IPv6 address.
To configure the Cisco RV110W to use a static IPv6 address:
STEP 1 Choose Networking > IPv6 > IPv6 WAN Configuration.
STEP 2 In the WAN Connection Type field, select Static IPv6.
STEP 3 Enter this information:
IPv6 Address Enter the IPv6 address of the WAN port.
IPv6 Prefix Length Enter the IPv6 prefix length defined by the ISP.
The IPv6 network (subnet) is identified by the initial
bits of the address which are called the prefix.
For example, in the 2001:0DB8:AC10:FE01::
IP address, 2001 is the prefix.
All hosts in the network have identical initial bits for
their IPv6 address; you set the number of common
initial bits in the network addresses in this field.
Default IPv6 Gateway Enter the IPv6 address of the default gateway. This
is the IP address of the server at the ISP that this
router connects to for accessing the Internet.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
