Cisco RV110W Administration Guide

Using Cisco QuickVPN
Using the Cisco QuickVPN Software
Cisco RV110W Administration Guide 152
A
STEP 3 In the User Name and Password fields, enter the User Name and Password that
were created in Creating and Managing QuickVPN Users.
STEP 4 In the Server Address field, enter the IP address or domain name of the
Cisco RV110W.
STEP 5 In the Port For QuickVPN field, enter the port number that the QuickVPN client
uses to communicate with the remote VPN router, or keep the default setting, Auto.
STEP 6 To save this profile, click Save.
To delete this profile, click Delete. For information, click Help.
NOTE If there are multiple sites to which you need to create a tunnel, you can create
multiple profiles, but only one tunnel can be active at a time.
STEP 7 To begin your QuickVPN connection, click Connect.
The connection progress displays: Connecting, Provisioning, Activating Policy,
and Verifying Network.
STEP 8 After your QuickVPN connection is established, the QuickVPN tray icon turns
green, and the QuickVPN Status window appears.
The window displays the IP address of the remote end of the VPN tunnel, the time
and date the VPN tunnel began, and the total length of time the VPN tunnel has
been active.
To terminate the VPN tunnel, click Disconnect. To change your password, click
Change Password. For information, click Help.
STEP 9 If you clicked Change Password and have permission to change your own
password, the Connect Virtual Private Connection window appears.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
