Cisco RV110W Administration Guide

Configuring Networking
Configuring IPv6
Cisco RV110W Administration Guide 58
2
STEP 3 Enter this information:
STEP 4 Click Save.
IPv6 Prefix Type Choose one of the following types from the
drop-down menu:
6to4—6to4 is a system that allows IPv6 packets to
be transmitted over an IPv4 network. It is used
when an end user wants to connect to the IPv6
Internet using their existing IPv4 connection
Global/Local—A locally unique IPv6 address that
you can use in private IPv6 networks or a globally
unique IPv6 Internet address.
SLA ID If you choose 6to4 as the IPv6 prefix type, enter
the Site-Level Aggregation Identifier (SLA ID).
The SLA ID in the 6to4 address prefix is set to the
interface ID of the interface on which the
advertisements are sent.
IPv6 Prefix If you choose Global/Local as the IPv6 prefix type,
enter the IPv6 prefix. The IPv6 prefix specifies the
IPv6 network address.
IPv6 Prefix Length If you choose Global/Local as the IPv6 prefix type,
enter the prefix length. The prefix length variable is
a decimal value that indicates the number of
contiguous, higher-order bits of the address that
make up the network portion of the address.
Prefix Lifetime Enter the prefix lifetime, or the length of time over
which the requesting router is allowed to use the
prefix.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
