Cisco RV120W Administration Guide

Configuring Virtual Private Networks (VPNs) and Security
Configuring Advanced VPN Parameters
Cisco RV120W Administration Guide 94
5
STEP 6 Choose the type of address for the local gateway (the Cisco RV120W):
• IP Address—Enter the IP address of the gateway in the box below.
• FQDN (Fully-Qualified Domain Name)—Enter the domain name in the box
below (for example, http://www.cisco.com).
STEP 7 If you chose gateway in Step 2, enter the IP address and subnet mask of the
remote LAN. The remote gateway to which the Cisco RV120W will connect is
located on that LAN.
NOTE The IP address range used on the remote LAN must be different from the IP
address range used on the local LAN.
STEP 8 Click Save.
Viewing the Default VPN Settings
To view the default VPN settings:
STEP 1 Choose VPN > IPsec > Basic VPN Setup.
STEP 2 Click View Default Settings. Settings cannot be changed from this page, but can
be configured through the Basic VPN Setup or Advanced VPN Setup menus.
Configuring Advanced VPN Parameters
The Advanced VPN Setup page allows you to configure advanced VPN
parameters, such as IKE and other VPN policies. These policies control how the
Cisco RV120W initiates and receives VPN connections with other endpoints.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
