Cisco RV120W Administration Guide

Configuring Virtual Private Networks (VPNs) and Security
Configuring Advanced VPN Parameters
Cisco RV120W Administration Guide 98
5
Extended Authentication (XAUTH) Parameters
Rather than configuring a unique VPN policy for each user, you can enable the VPN
gateway router to authenticate users from a stored list of user accounts or with an
external authentication server such as a RADIUS server. When connecting many
VPN clients to a VPN gateway router, Extended Authentication (XAUTH) allows
authentication of users with methods in addition to the authentication method
mentioned in the IKE SA parameters. XAUTH can be configured in the following
modes:
STEP 1 Select the XAUTH type:
• None—Disables XAUTH.
• Edge Device—Authentication is done by one of the following:
- User Database—User accounts created in the router are used to
authenticate users. See Configuring VPN Users, page 105.
- RADIUS-PAP—Authentication is done using a RADIUS server and
password authentication protocol (PAP).
- RADIUS-CHAP—Authentication is done using a RADIUS server and
challenge handshake authentication protocol (CHAP).
• IPsec Host—The router is authenticated by a remote gateway with a
username and password combination. In this mode, the router acts as a VPN
Client of the remote gateway.
STEP 2 If you selected IPsec Host, enter the username and password for the host.
Configuring VPN Policies
To configure a VPN policy:
STEP 1 Choose VPN > IPsec > Advanced VPN Setup.
STEP 2 In the VPN Policy Table, click Add.
STEP 3 Enter a unique name to identify the policy.
STEP 4 Choose the Policy Type:

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
