Cisco RV120W Administration Guide

Configuring Quality of Service (QoS)
Configuring Profile Binding
Cisco RV120W Administration Guide 114
6
STEP 3 Enter this information:
STEP 4 Click Save.
STEP 5 To bind the profile to a traffic selector, see Configuring Profile Binding, page 114.
Configuring Profile Binding
After creating WAN QoS profiles, you must bind them to traffic selectors.
To create a profile binding:
STEP 1 Choose QoS > Profile Binding.
STEP 2 In the Available Profiles field, choose a WAN QoS profile.
To create a profile, click Configure Profile. See Configuring WAN QoS Profiles,
page 112 for more information.
STEP 3 From the Service drop-down menu, choose the service the profile applies to.
If the service you are looking for is not in the drop-down menu, you can configure a
custom service in the Firewall page (see Creating Custom Services, page 83.)
STEP 4 From the Traffic Selector Match Type drop-down menu, choose the traffic selector
to use to bind traffic to the profile.
Name Enter the name of the profile.
Priority If the WAN QoS mode is set to Priority, choose the
priority level from the drop-down menu.
Minimum Bandwidth
Rate
If the WAN QoS mode is set to Rate Limit, enter the
minimum bandwidth rate (1 to total WAN
bandwidth in Kbps).
Maximum Bandwidth
Rate
If the WAN QoS mode is set to Rate Limit, enter the
maximum bandwidth rate (100–1000000 Kbps).

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
